ACT - XT/Race Sprung 6 Pad (NZ1-XTG6) 2003-2007 | INFINITY G35

ACT - XT/Race Sprung 6 Pad (NZ1-XTG6) 2003-2007 | INFINITY G35

Vendor: ACT

Available: In stock

SKU: actNZ1-XTG6

$649.00

NZ1-XTG6 kit features an Xtreme pressure plate for the most demanding driver. ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life....

FAST SHIPPING

On all products!


RETURNS

60 days return policy


TELEPHONE SUPPORT

(239) 270-5116

NZ1-XTG6 kit features an Xtreme pressure plate for the most demanding driver. ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT's 6-pad spring-centered race disc features a spring-center construction to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad spring-centered disc is recommended for larger clutch sizes to absorb more heat.

Feel: Moderate to heavy pedal effort, aggressive engagement, OE to mild gear rattle;

Life: Moderate friction life, extended by ACT's exclusive diaphragm design;

Quality: Carefully engineered, precisely assembled, accurately balanced, uses select ceramic friction materials for high heat tolerance and maximum performance;

Recommended Use: Recommended for high horsepower street or race use;

ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability;

Dimensions (L/W/H)
14x14x5
Weight
21.5 lbs
MSRP
$832.00
Warranty
12 Months
Product Weight (lbs.)
18
Input Shaft Diameter (Inches)
1
Spline Count
24
Disc Type
Sprung Race Disc
Friction Surface Diameter (Inches)
9.8
Friction Surface Diameter (mm)
250
Pressure Plate Type
Xtreme
Torque Capacity Over OE
83%
Torque Capacity (ft/lbs.)
669
ItemCodeDesc
XT/Race Sprung 6 Pad
Disc Material
Ceramic
Pad Quantity
6
Alignment Tool Included
AT01
Pilot Bushing Included
PB1012
Release Bearing Included
RB130
